F
F
F
W
W
W
W
Setup examples
The three examples to the left all
show the loudspeaker placed more
than 50 cm (20") from the rear wall
– and therefore the POSITION switch
should be set to F.
The four examples to the right all
show the loudspeaker placed closer
than 50 cm (20") from the rear wall
– and therefore the POSITION switch
should be set to W.
If the loudspeaker is fi tted to either
the Motorised Table Stand or the
Table Stand – and you have chosen
to place it on the fl oor – you should
set the POSITION switch to W.
NOTE! BeoVision 7 and the
accessories shown in the examples,
are not available on all markets!
9
