Fan motor electrical data, Defrost heater electrical data, Refrigerant charge – Bally Refrigerated Boxes BJBF Electric, and Hot Gas Defrost Blast Freezers User Manual
Page 3
REFRIGERANT CHARGE
- 3 -
FAN MOTOR ELECTRICAL DATA
DEFROST HEATER ELECTRICAL DATA
† Amperage draw on phase with maximum load. (Operating current only)
* Electrical wiring is to be sized in accordance with minimum ampacity rating.
M.C.A. = Minimum Circuit Ampacity • M.O.P. = Maximum Overcurrent Protection
208-230/3/60
460/3/60
575/3/60
Model
BJBF
Fan
Motor
Qty/HP
Type of
Motor
Total
F.L.A.
M.C.A.
M.O.P.
Total
F.L.A.
M.C.A.
M.O.P.
Total
F.L.A.
M.C.A.
M.O.P.
063 069 075
078 084 090
092 099 105
108 114 120
2/3
Standard
TEFC
17.2/16.8
19.4
25
8.4
9.5
15
7.0
7.9
15
111 122 130
132 142 150
153 163 170
3/3
Standard
TEFC
25.8/25.2
28.0
35
12.6
13.7
20
10.5
11.4
15
208-230/3/60
460/3/60
575//3/60
Model
BJBF
Fan
Motor
No.
Total heater
kW
Total
Amperes
M.C.A.
M.O.P.
Total
Amperes
M.C.A.
M.O.P.
Total
Amperes
M.C.A.
M.O.P.
063 069 075
2
14.0
38.1/42.2
40/48
50/60
21.1
24
30
16.9
20
25
078 084 090
2
19.6
48/53.1
48/56
60/70
26.5
28
35
21.2
24
30
092 099 105
2
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
108 114 120
2
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
111 122 130
3
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
132 142 150
3
25.2
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
153 163 170
3
28.0
67/74.1
72/80
90/100
37.0
40
50
29.6
32
40
MODEL BJBF
R-22
R-404A
R-502
lb
kg
lb
kg
lb
kg
063
069
075
34.2
15.5
32.9
15.0
37.6
17.1
078
084
090
45.6
20.7
43.9
19.9
50.1
22.8
092
099
105
57.0
25.9
54.8
24.9
62.7
28.5
108
114
120
68.4
31.1
65.8
29.9
75.2
34.2
111
122
130
60.8
27.6
58.5
26.6
66.9
30.4
132
142
150
76.0
34.5
73.1
33.2
83.6
38.0
153
163
170
91.2
41.5
87.7
39.9
100.3
45.6
Refrigerant charge with 30% full coil @ 20 °F S.S.T. (R-22), -20 °F S.S.T. (R-404A, R-502)
