9
4.2. OSD MENU Adjustments and Settings
The following table shows all adjustment and setting menus.
Main Menu Sub Menu Reference
Input
Main Input Source Selection:
VGA/DVI/S-video/CVBS/SDI
Brightness Digital brightness setting ：
(Value: 0 – 100)
Contrast Digital contrast setting ：(Value: 0 – 100)
Sharpness Set Sharpness：(0-24)
Aspect Ratio Picture scaling mode：
(5:4/ 4:3/Full /Full Aspect/ Native/ User)
Mode Select According to Mode Selection
Color temp Color Temp Setting：
5500K, 6500K, 7500K, 8500K, 9300K,
10000K, USER
Gamma 3.0, 2.8, 2.6, 2.4, 2.2, 2.0, 1.8
OSD Position Adjust the location of the OSD menu：
(Center/Top Left/Top Right Bottom Left/Bottom
ight)
OSD Language Select language of the OSD menu ：(English/
中文
)
Auto Scan Input The monitor would auto scan video source or
not : (On /off)
Setup
Factory Reset Recall the default value
Auto Adjust Automatically Adjust the picture
H-position Set the horizontal position
V-position Set the vertical position
Clock According to the pattern choice
VGA
Phase According to the pattern choice
FW version Information about the version of software
Main Input Information about the current Main video
source
Status
Main Format Information about the current Main timing
4.3. Screen Adjustment
Screen adjustments for the LCD monitor should be used in suppressing screen
flickering and also for adjusting the screen to its proper position. There is only one
correct position for each display mode. It is also recommended to use the OSD Menu
function when first installing the display or whenever changing the system.
Note: Allow the LCD monitor to stabilize for at least 20 minutes before making image
adjustments. Making Adjusting must be VGA signal.
Making adjustment must be VGA signal.
