MONITOR MODULE
(1) Channels to monitor
(2) A output to monitor
(3) B output to monitor
(4) A-B output to monitor
(5) C output to monitor
(6) D output to monitor
(7) C-D output to monitor
(8) Stereo-return 1 to monitor
(9) Stereo-return 2 to
(10) Monitor 1 left output-level control
(11) Monitor 1 right output-level control
(12) Monitor 1 output
(13) Matrix selector & indicator
(14) Mono of monitor outputs
& indicator
(16) Reverse talkback & PFL
level control
(15) Monitor 2 right output-level control
(17) Talk to external
(18) Talk to A/B outputs
(19) Talk to C/D outputs
(20) Internal
(21) Internal
microphone
