12
DD MM YY XX
When working with an Aaton or Aaton system cameras, or setting the Internal
RTC this format must be used.
1.3.7 The AMPS configuration
DD MM UR RR
Use this format when more identification numbers are required.
1.3.8 The Time Field
The time field has the following fixed configuration:
H= Hours M= Minutes S= Seconds F= Frames
HH MM SS FF
When the display is running the frame field is changing at the frame rate. In
the set mode the FF position can contain the following digits and letters which
indicate the frame rate selected by the DIP-switches or modes for setting the
RTC.
1.3.9 The Frame (FF) Digits
Display 24 25 23 29 2d 30 3d ct cd
Fps 24 25 23.98 29.97 29.97 30 30 set set
Drop Drop RTC RTC from
Frame Frame Gen. TC Manual Displ.
Note: The frame rate displayed is an indication of the DIP-switch setting and cannot
be changed by the cursor.
1.3.10 The CD and CT functions
The ct or cd function can be selected in the FF position.The slate must also
be in the generator /RTC mode.
Select ct
When Load is implemented the RTC is set from the generator time
and date.
Select cd
When Load is implemented the RTC is loaded from the current
display time and date. (Set manually)
Select Fps (DIP-switch value shown)
