AJA Control Room v1.0 www.aja.com 15
Capture Clip Settings: The Capture Tab provides the Clip Settings pane (shown below) that allows you to enter
meta-data and library information for the clip you will create. In the top row, from
pulldown menus, you will select format options for the file:
• File Type
• Video format (from those supported by the File Type)
• Audio Format (from those supported by the File Type)
A Clip Name will be generated automatically or you can choose to enter your own
designations for:
• File Name,
• Reel name
• Scene description
• Take designation.
NOTE: If you want your information to be displayed as part of the Clip Name in AJA Control Room,
you must enable the check boxes to the right of the entry field. The plus (+) buttons are used to
add/increment a numeric designation.
Figure 16. Capture Tab Settings Pane
Audio Channel Selection: To select audio channels for capture:
• Single click to enable/disable channels in pairs or
• Option-click to enable/disable all available channels.
