Io XT/4K v10.5r2

www.aja.com

58

Machine Control

• • RS-422, Sony 9-pin protocol

• • 9-pin D-connector pinout is as follows:

1.

GND

2.

RX-

3.

TX+

4.

GND

5.

No Connection

6.

GND

7.

RX+

8.

TX-

9.

GND

Shell. GND
