50
Audio Input Digital
•
8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
•
8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
Audio Output Digital
•
8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
•
8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
Audio Output Analog
•
2-channel 24-bit unbalanced audio (via RCA jack)
Reference Input or LTC Input
•
1 BNC assignable to Reference video or LTC input
•
Reference:
•
Analog Color Black (1V) or Composite Sync (2 or 4V)
•
Non terminating
Machine Control
•
RS-422, Sony 9-pin protocol (via breakout cable or optional K3G-Box)
•
9-pin D-connector pinout is as follows:
1 GND
2 RX-
3 TX+
4 GND
5 No Connection
6 GND
7 RX+
8 TX-
9 GND
Shell GND
Physical
•
Power: 12-18V, 11-13W
•
Interface: PCI Express x1
