3 AJA D10CEA SDI to Component/Composite Converter User Manual — Introduction
Introduction
The D1OCEA converts SDI video with embedded audio to 10-bit component or
composite analog video and 4 channel balanced analog audio. The video outputs can
be configured as YPbPr (Betacam or SMPTE/EBU N10), RGB, composite or Y/C
(S-Video). Two re-clocked loop-thru SDI outputs are also provided. This versatile
low-cost converter is ideal for video/audio monitoring.
The 4 channel analog audio outputs can be wired in a balanced or unbalanced
configuration. All audio output channels can be selected as group 1-4 from SMPTE
embedded audio. You have four settings of Audio level to choose from.
Output connections for video and audio are available on a 25 pin “D” subminiature
connector. A break-out cable is supplied with the converter for this purpose.
You can configure video and audio from a DIP switch accessed through a cut-out in
the converter’s case.
Features
• SDI to analog audio and video converter
• SDI with embedded audio input
• 2 re-clocked, loop-thru SDI outputs
• 10-bit component or composite analog video outputs
• 4 channel balanced analog audio output
• Selectable audio level
• Selectable audio channel group
• External DIP switch user interface for configuration
