Appendix A: Specifications
Video
Video Input 3G/HD/SD-SDI, SMPTE-259/292/424 (with embedded audio) 1 x BNC
Input Formats: • 525i, 625i,
• 720p 50/59.94/60,
• 1080i 50/59.94/60,
• 1080p23.98/24/25/29.97/30/50/59.94/60
• 1080psf23.98/24/25/29.97/30
• 2Kx1080p23.98/24/25/29.97/30/50/59.94/60
• 2Kx1080psf23.98/24/25/29.97/30
Video Output HDMI (with embedded audio)
HDMI Standard Type A connector
• Video (selectable by MiniConfig):
• 8-bit RGB 4:4:4 or
• 10-bit YCbCr 4:2:2
• 12-bit
HDCP The Hi5-Plus does not encode the HDMI output with HDCP encryption.
Audio
SDI Audio Input Eight channels (4 pairs) of embedded audio supported
• Select Ch 1-8 or Ch 9-16
• 24-bit/48 KHz
HDMI Audio Output Up to eight channels (4 pairs) of embedded audio supported, selectable by MiniConfig:
• Two embedded channels, or 8 embedded channels
• 24-bit/48 KHz
Analog Audio Output Unbalanced, -10dBV (nominal), 2 x RCA
Routing of incoming embedded audio channel pairs to the analog outputs selectable by
MiniConfig:
• Ch 1-2 (or 9-10), through Ch 7-8 (or 15-16)
Physical
Size 4.6" x 2.4" x 1" (117mm x 61mm x 25mm.)
Power • Uses AJA Power Supply model DWP-U-R1 (included)
• 100-240V, 50/60Hz Universal Input
• +5V DC regulated, 3 watt capacity
