AJA CamXchange Application v1.1

www.aja.com

7

Configuring the AJA Ki Pro Quad Settings

Figure 3. AJA Ki Pro Quad

1. Depress the CONFIG button on the AJA Ki Pro Quad.

2. Use the SELECT up/down buttons to navigate the menu parameters. Use the ADJUST

up/down buttons to make choices within the menu parameters.

3. Select the following:

• 1.1 Record Type>Normal.

• 1.4 In Convert>None.

• 2.1 Video Input>SDI 1 RAW.

• 8.0 TC In>SDI RP188.

• 13.1 Camera Data>Canon C500.

Next, you will review the AJA CamXchange application user interface.
