5 Ki Pro Quick Start Guide— A quick synopsis of the parameters in the CONFIG menu
8.1 TC Value This parameter selects an hour for timecode to start. Each subsequent recording after the first
time you set this value will increment until you reset the value. If you start with a recording at
01:00:00:00 and end at 01:00:14:11, then your next recording begins at 01:00:14:12.
8.2 TC Type This parameter selects drop frame or non-drop frame timecode.
Since the goal of this Quick Start Guide is to give you a basic understanding of configuring Ki Pro
Mini, we will skip over the configuration of the ethernet and wireless parameters. For more
detailed information on how to configure these parameters, consult the Ki Pro Mini Manual.
8.3 Arm Recording This parameter selects how recording will begin: either by pressing record button (or web
“Record” button) or via timecode.
41.1 Video SG Frmt This parameter determines the video format output from Ki Pro Mini’s internal test signal
generator.
41.2 Video SG This parameter determines the video signal output from Ki Pro Mini’s internal test signal
generator.
41.3 Audio SG This parameter determines the audio signal output from Ki Pro Mini’s internal test signal
generator.
50.1 IP Config This parameter determines the type of TCP/IP network configuration used by Ki Pro Mini.
50.2 IP Address This parameter determines the static IP address used by Ki Pro Mini for TCP/IP networking.
50.3 Subnet Mask This parameter determines the subnet mask used by Ki Pro Mini for TCP/IP networking.
50.4 Static Gateway This parameter determines the gateway or router used by Ki Pro Mini on your LAN for
TCP/IP networking.
50.5 System Name This parameter defines a name for Ki Pro Mini and gives it a unique identifier. This same name is
used both when displaying systems via the web interface.
50.6 MAC Address This parameter is an information only field showing the MAC address of the Ki Pro Mini’s
ethernet adapter.
56.1 Date Set This parameter manually sets the calendar date of the internal Ki Pro Mini clock. The value is
defined as YYYY/MM/DD (year/month/day). Using the adjust buttons, enter a calendar date for
Ki Pro Mini.
Using the adjust buttons and the top SELECT button, select the characters for each category
(YYYY/MM/DD). The adjust buttons scroll through the choices and the top SELECT button
advances to the next character. While selecting characters, the character being changed will
flash to show its position. When finished, the final press of the SELECT up button will flash the
whole value, hit SELECT once more to confirm and the next menu parameter will appear.
56.2 Time Set This parameter manually sets the calendar date of the internal Ki Pro Mini clock. Please note
that this time is based on GMT (Greenwich Mean Time) so if you are in another timezone, you
will need to remember to set this accordingly and not necessarily to the time you see on your
watch. Also note that the clock is 24 hour mode, not 12 hour display mode.
Using the adjust buttons, enter a time for Ki Pro Mini’s clock. Using the adjust buttons and the
top Select button, select the characters for each digit (hours/minutes). The adjust buttons scroll
through the choices and the top Select button advances to the next character. While selecting
characters, the character being changed will flash to show its position.
When finished, the final press of the SELECT up button will flash the whole value, hit SELECT
once more to confirm and the next menu parameter will appear.
70.2 Display Intensity This parameter determines the brightness of the alphanumeric LCD display and front panel
backlit buttons.
70.3 Fan Speed This parameter determines the speed of Ki Pro Mini’s internal cooling fan. In some environments
where audio recording is occurring close to the Ki Pro Mini unit, it may be desirable to set the fan
speed to “QUIET RECORD” for optimum quiet operation.
After you've made the settings that you desire in the CONFIG parameters, you can exit the menu
by either hitting the CONFIG button again or hitting the STOP button.
