Express® Lavatory System SS-Series
Installation - Obsolete SS-3/AST/WH97TAS
15 Bradley Corporation • 215-1240 Rev. E; EN 08-805 4/24/08
Assembly of Components
Vernatherm™ Thermostatic Mixing Valve
Assembly S67-571
FLEX HOSE WITH
SWIVEL END
269-653
STOP/CHECK
VALVE
S27-102
FILTER
WASHER
269-1188
VERNATHERM
VALVE
(S01-116B)
Optional Stop/Strainer/Check Valve
STOP/STRAINER/CHECK
VALVE S60-003
90° ELBOW
169-639
1/2 NIPPLE
(113-006DJ)
