Express® Lavatory System SS-Series
Installation - Obsolete
SS-3/AST/WH97TAS
11
Bradley Corporation • 215-1240 Rev. E; EN 08-805
4/24/08
Installation Instructions continued . . .
Step 5: Completing installation
1. Turn on the water supply to the Express® and check for leaks.
2. Install the panel to the frame. Fasten panel with the nine Torx-head screws provided (see
Figure 8 below).
Figure 8
FRAME
(10) TORX-
HEAD SCREW
PANEL
