1
1. Specifications
Model BM400 BO600
Temp. range during operation Room temp. +5 ℃ ∼ 95℃ *1 Room temp. +5 ℃ ∼ 180℃
Temp. setting range 0 ℃∼100℃ 0 ℃∼200℃
Accuracy of temp. adjustment *2 ±1 ℃ at 60℃ ±2 ℃ at 100℃
Control system PID Control by Micro Computer
Set-up system Digital Setting By △▽Key
Display system Digital display shows the measured/set temp.
Resolution to display/set 1 ℃
Operation function Operation at fixed point
Extra function Temp. presetting function (preset/select one temp.)
Sensor Pt100 Ω
Material SUS316 pipe heater
Heater
Capacity 1kW
Power switch Also functions as a circuit protector
Others Drain (with plug) , Service outlet for RE
Safety device
1. Self-diagnostic Functions
Automatic Overheat Prevention, Sensor Trouble,
TRIAC short, Heater disconnection, Main relay trouble
2. Circuit protector
3. Tank protection cover
4. Thermofuse
Capacity 7000ml
Tank
Dimension *3 φ250×Depth 150 (mm)
External dimensions (W ×D×H) *3 310 Ч360Ч230 (mm)
Weight 7kg 8kg
Required power source AC100V ±10％ 50/60Hz 10 A
Liquid used Water Silicon oil
Standard accessories
● Operation manual 1
● Warranty 1
*1 In case of unloaded operation of bath only. The maximum temperature varies on circumstances
and operational conditions.
*2 It shows the performance under rated power supply at the room temperature of 23 ℃± ± ± ±5℃ and with
humidity of 65% ± ± ± ±20%.
*3 It does not include projection parts.
