SPECIFICATIONS
Description: Designed for use with a crane or other hoisting equipment, P2-DC2(O) lifters employ
vacuum to hold a load for lifting, and they provide manual 180° rotation and manual
90° tilt movements for load manipulation.
Model Number: P2110445DC2(O) P211047DC2(O) P2HV110445DC2(O) P2HV11047DC2(O)
Vacuum Pads: (8 each, standard rubber, with #60 filter screen)
11" [28 cm] nominal diameter, lipped
(Model G3370)
10" [25 cm] nominal diameter, lipped
(Model HV11 1 )
Maximum Pad Spread: 51" x 54¼" 51" x 84¼" 50" x 53¼" 50" x 83¼"
(to outer edges) [1295 x 1378 mm] [1295 x 2140 mm] [1270 x 1353 mm] [1270 x 2115 mm]
Maximum Load Capacity: 2
Per-Pad: 175 lbs [79.5 kg] 150 lbs [68 kg]
Overall: 1400 lbs [635 kg] 1200 lbs [545 kg]
Lifter Weight: 197 lbs [87 kg] 210 lbs [96 kg] 201 lbs [92 kg] 214 lbs [97 kg]
Power Source: 12 volts DC, 4.5 amps (for each pad channel)
Battery Capacity: 7 amp-hours
Rotation Capability: Manual, 180°, with automatic locking at each ¼ revolution (when desired)
Tilt Capability: Manual, 90°, with automatic locking in vertical position
Options: Available with Model EO8RC1 - Remote Control Systems with 310-320 or 433-434
MHz radio signal, depending on requirements in your geographical location.
See separate instructions about other options.
Operating
Elevation:
Maximum = 6000 feet [1828 meters]
Operating
Temperatures:
32° to 104° F [0° to 40° C]
Service Life: This lifter is designed to have a service life of at least 20,000 lifting cycles, when
used and maintained as intended (vacuum pads, filter elements and other wear-out
items are excluded).
ASME Standard BTH-1:
Design Category "B", Service Class "0" (see www.powrgrip.com for more
information)
!!–CE–!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are different from
requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory in geographical areas
where CE Standards apply, but may be optional in other locations.
1
Available with optional closed-cell foam rings for applications on rough or textured surfaces (Model HV11F ).
2
The Maximum Load Capacity is rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces, with a friction coefficient
of 1 (see MAINTENANCE: V ACUUM P AD M AINTENANCE : Pad to Load Friction Coefficient). A qualified person should evaluate the
effective lifting capacity for the actual application. In addition to the effect of friction between the vacuum pads and load, the
lifting capacity may be affected by the following load characteristics: rigidity, strength, surface conditions, overhang, angle, center
of gravity and temperature.
