Wood’s Powr-Grip PCFT2SA47 - Manual (Page 28)

Rev 0.0/11-13 26 P2-DC2: #35114
MAINTENANCE
Note: Each pad channel on this vacuum lifter has an independent vacuum generating system.
All directions about controls and other operating features in the MAINTENANCE section must be
carried out for both pad channels, in order to fulfill inspection, testing and maintenance
requirements. Refer to
SERVICE MANUAL #36100 when applicable.
Make sure both batteries are disconnected before servicing lifter.
I
NSPECTION
S
CHEDULE
Perform inspections routinely, according to the following frequency schedule. If any deficiency is
detected, correct it before using the lifter (see SERVICE MANUAL when necessary) and perform
the next most frequent inspection.
Action Every Lift Frequent 17
(20-40 hours)
Periodic 18
(250-400 hours)
Examine the vacuum pads for contamination or
debris, and clean them as necessary (see V
ACUUM
P AD M AINTENANCE : Pad Cleaning).
X X X
Examine the vacuum pads for visual damage. X X X
Examine the load surface for contamination or
debris, and clean it as necessary.
X X X
Examine all controls and indicators for visual
damage.
X X X
Test both batteries for adequate charge. If
necessary, charge and retest a battery (see
B
ATTERY
R
ECHARGE
to follow).
X X X
Examine the lifter’s structure for visual damage. X X
Examine both vacuum systems (including vacuum
pads, fittings and hoses) for visual damage.
X X
Examine all air filters for conditions requiring
service.
X X
Perform the V
ACUUM
T
EST
. X X
Check for unusual vibrations or noises while
operating the lifter.
X X
If the lifter is equipped with Remote
Control Systems, perform the R EMOTE
C
ONTROL
S
YSTEMS
T
EST
.
X X
17
The Frequent Inspection is also required whenever the lifter is out of service for 1 month or more.
18
The Periodic Inspection is also required whenever the lifter is out of service for 1 year or more. If necessary, return the lifter
to Wood’s Powr-Grip or an authorized dealer for repair (see LIMITED WARRANTY).
