1. Overview
The Serial/Ethernet converters from Weidmüller deliver easy and
reliable serial-to-Ethernet connectivity for the industrial automation
market. The converters support several operation modes - TCP Server,
TCP Client, UDP, Real COM, RFC2217, RTelnet, Pair Connection, and
Ethernet Modem - ensuring the compatibility of network software, and
are an ideal choice for connecting RS-232/422/485 serial devices, such
as PLCs, sensors, meters, motors, drives, barcode readers, and
operator displays.
2. Package Checklist
Before installing the Serial/Ethernet converter, verify that the package
contains the following items:
• 1 Serial/Ethernet Converter
• Documentation and Software CD
Æ Please download CD-ROM content from Internet
page http://www.weidmueller.com/downloads
Æ For manual select
Section
Com-Port driver or Firmware Update select
Ethernet>
• 1 Hardware Installation Guide
If any of these items are missing or damaged, please contact your
Weidmüller customer service for assistance.
.
3. Hardware Introduction
The IE-CS(T)-2TX-
1
RS232/485 is equipped with one RS-232 DB9
serial port and one RS-422/485 terminal block for serial data
communication.
The IE-CS(T)-2TX-
2
RS232/485 is equipped with two RS-232/422/485
3-in-1 DB9 serial ports for serial data communication.
Each model has one 8-contact screw-type terminal block, which is
located on the top for power input and relay output.
