Mehrleiteranschlu§ max. 1 mm, Zwei leiter gleichen querschnitts), Multi-wire conncection max. 1 mm – Weidmuller WAVE Analog PRO Thermo User Manual
Page 10
23
4.
Mounting
Die The analogue signal isolators are mounted on standard TS 35 rails.
5.
Electrical connection
Warning! For applications with high isolation voltages, take measures to
prevent accidental contact and make sure that there is suffi-
cient distance or insulation between adjacent devices!
5.1 Power supply
approx. 1 W
18…30 Vdc
Voltage supply via cross-connections. Operating carrying capacity of cross-
connection
Յ 2 A (see Cat. No. point 7)
Klemmenbelegung
1 Eingang +
> 5 mA
2 Eingang +
≤
500 mV /
≤
5 mA
3 Eingang +
> 500 mV
4 Eingang -
5 Ausgang +
6 Ausgang -
7 Versorgungsspannung
8 Versorgungsspannung
Anschlu§querschnitt max. 2,5 mm
2
Mehrleiteranschlu§ max. 1 mm
2
(zwei Leiter gleichen Querschnitts)
7 8
10
1
2
3
9
11 12
WAS5 PRO Thermo
7
8
24V
Th
1
3T
h
nc
2
I
0/4...20mA
0...10V
V
8560720000
9
0V
10
11
12
cc
nc
We dm ü l le r
i
0
V.
q
V/IV/I
PSPS
06 06
cccc
Terminal assignments
1 Thermo +
2 not assigned
3 Thermo –
7 Output + 0/4…20 mA
8 Output + 0…10 V
9 Output 0 V
10 Power supply + 24 Vdc (cross connected)
11 Power supply GND (cross connected)
12 not assigned
Wire cross-section max. 2.5 mm
2
Multi-wire conncection max. 1 mm
2
(two wires with same cross-section)
