22
Selecting the output
Switch 2
Output 5 6 7 8
0...20 mA 0 0 0 0
ready
Selecting the frequency
Switch 2
C 1 2
x100 1 0
Selecting the frequency
Switch 1
B 5 6 7 8
0.1 0 0 0 1
Selecting the frequency
Switch 1
A 1 2 3 4
8 1 0 0 0
Selecting the operating mode
Switch 2
Operating mode 3 4
fmin...fmax 0 1
Selecting the frequency
Switch 2
C 1 2
x1 0 0
Selecting the frequency
Switch 1
B 5 6 7 8
0.6 0 1 1 0
Selecting the frequency
Switch 1
A 1 2 3 4
3 0 0 1 1
Selecting the operating mode
Switch 2
Operating mode 3 4
save from fmin 1 0
Set max. frequency
3.5 Example 2
Input frequency: 3,6...810 Hz
Output: 0...20 mA
Set min. frequency
The module must be briefly con-
nected to the power supply (5s) in
order to save the min. frequency.
