1. General instructions
Warning! The analogue signal isolators of the WAVE
ANALOG
PRO Frequency may only be installed by qualified personnel.
Be sure not to connect the unit to power supply before
appropriate installation. Do not select ranges during operation,
because live parts are exposed during this process. Only use a
screwdriver which is properly insulated against the voltage
applied to the input when fine adjusting the potentiometers on
the front.
Be sure to observe the national regulations for installation and
selection of cables.
Appropriate safety measures against electrostatic discharge
(ESD) should be taken during assembly and adjustment work on
the WAVE
ANALOG
PRO Frequency.
2. Application
Analog signal isolators WAVE
ANALOG
PRO Frequency PRO are used for
galvanic isolation and conversion of frequency signals.
Input and output signals can be calibrated/switched via DIP switches.
It is not necessary to adjust the pre-settable measurement ranges.
The output signal is linear to the frequency.
