Weidmuller WAVE Analog OLP - Manual (Page 4)

9
WAVE ANALOG
OLP
8543720000/8543730000
7
8
9 1
2
3
PLC
230Vac
24Vdc
~
R
L
4 ... 20mA 0...10V
24Vdc
230Vac
~
3. Configuration
3.1 Equipment
A screwdriver with a width of 2.5 mm is required to adjust the unit and to
connect the wires to the terminals.
3.2 Opening the unit
Disconnect the plugs. Disengage the top part of
the housing by carefully pressing the latches on
both sides (1). Pull out the top part of the hou-
sing and the electronics section until they lock
(2).
3.3 Application
1
1
2
