Technical Specifications
Quick Reference Guide
25
Technical Specifications
The following table contains Physical and Performance Char-
acteristics, User Environment and Regulatory information.
Item
Description
Physical Characteristics
Color
Black
/Yellow
Dimensions
Height 7.1”/181 mm
Length 3.9”/100 mm
Width 2.8”/71 mm
Weight (without cable)
Approximately 6.9 ounces /195.6 g
Electrical Characteristics
Voltage & Current
Input Voltage
• 5.25VDC
Operating (typical)
• 160ma
Operating (max)
• 350ma
Idle/standby (typical)
• 65ma
Performance Characteristics
Light Source
LEDs
Roll (Tilt) Tolerance
Up to ± 180°
Pitch Tolerance
± 40°
Skew (Yaw) Tolerance
± 40°
Print Contrast Minimum
25% minimum reflectance
