Reading Parameters
20 WDI4600
Reading Parameters
Move the reader toward the target and center the aiming pat-
tern and illumination system to capture and decode the image.
See
Using the WDI4600 on page 7 for more information.
The aiming system will briefly switch off after the acquisition
time, and if no code is decoded will switch on again before the
next acquisition. The illuminator will remain on until the
symbol is decoded.
As you read code symbols, adjust the distance at which you are
holding the reader.
Aiming System
A number of options for customizing control of the Aiming
System are available. See the WDI4600 PRG for more infor-
mation and programming barcodes.
Good Read Green Spot Duration
Successful reading can be signaled by a good read green spot.
Use the barcodes that follow to specify the duration of the
good read pointer beam after a good read.
ENTER/EXIT PROGRAMMING MODE
Disabled
♦ Short (300 ms)
Medium (500 ms) Long (800 ms)
