Vortex Optics CROSSFIRE 3X32 CROSSBOW - CROSSBOW ILLUMINATED User Manual
Page 4
6
7
Illumination Adjustment
The Vortex 3x32 Crossbow scope uses a variable reticle
illumination system for additional reticle brightness when
needed—select between five different intensity levels for
the desired brightness. Colored indicators guide the shooter
in choosing between red or green illumination, depending
on preference. To activate the illumination, rotate the left
side adjustment knob in either direction off the zero setting.
The illumination is powered by a standard lithium CR2032
3-volt battery. To change the battery, unscrew the outer cap
on the illumination knob. Remove old battery and replace
with new, keeping the numbered face of battery facing
outwards.
Changing the battery
Mounting the Crossbow
Using standard 1-inch medium height rings and following
manufacturers instructions, mount the Crossfire Crossbow 3x32
scope to the Weaver type rail on your crossbow.
Be sure all mounting screws are secure
before shooting your crossbow.
