PhotoDoc-It Imaging System
6
Printer Installation
1. Install the ink cartridge: Open the panel on the right side of the printer. Insert the ink cassette into the printer until
it clicks firmly into place. Close the cover.
2. Insert the paper cassette: Open the panel on the front of the printer. Slide the lid off of the paper cassette. Place
paper in the cassette with the shiny side up. Try not to touch the shiny side of the paper. Close the lid. A portion of
the paper should be seen through the opening. Insert the cassette into the slot on the printer.
3. Attach the power cord to the printer and plug into a wall outlet or surge protector.
4. Attach the USB interface cable under the terminal cover on the side of the camera to the USB port on the left side
of the printer.
Connecting the Combination Lock
Attach the cable lock through the key ring on the camera and through the white handle on the hood.
