Electra Steer Diagnosis Trouble Code Reading and Code Clearing

1. Verify that your trouble code light is on steady.

2. Next, take your dark purple wire and hold it to a good clean ground. You will have to make sure it is a solid

ground to get the LED to blink or flicker and you may have to use a jumper wire to extend the wi

re’s length.

Once you see the LED flicker or blink wait for LED to start blinking a code.

3. The light will flash in a sequence like 1 and then 123. This code flash would be interpreted as a code 13. The

code will repeat itself 3 times and then go to the next code if there is one in the system. You need to wait until
all the codes are read and recorded.

4. Turn off the unit and turn back on. Once light is lit and staying on, touch the dark purple wire 6 times in a row

to a ground. After the 6 times turn unit off and turn back on. Codes should be cleared with the unit working
properly. If not continue to step 5.

5. Double check the codes using steps 1 through 3. Once you know what the codes are you can use this chart to

tell where or what the problem may be.

6. Once you have determined what the problem is and make the necessary repairs the unit should work

normally. If the light is still on after the repair you will need to clear the codes using step 4.

Trouble Code

Problem

Diagnosis

41-42-43-44-45-51

Electric motor

Malfunction

Replace Motor Assembly

11-13-14-15

Torque Sensor

Replace Motor Assembly

52-54-55

ECU Malfunction

Change Computer

22

No Engine Input

Change Computer

21-23-24

No Speed Signal

Change Computer

12

Wiring or

Electrical

Verify 12 volts at small red wire. Verify

good ground. Soldier all connections. Check

for bad connections or broken wires.
