Electra Steer Diagnosis Trouble Code Reading and Code Clearing
1. Verify that your trouble code light is on steady.
2. Next, take your dark purple wire and hold it to a good clean ground. You will have to make sure it
is a solid ground to get the LED to blink or flicker and you may have to use a jumper wire to
extend the wire’s length. Once you see the LED flicker or blink wait for LED to start blinking a
code.
3. The light will flash in a sequence like 1 and then 123. This code flash would be interpreted as a
code 13. The code will repeat itself 3 times and then go to the next code if there is one in the
system. You need to wait until all the codes are read and recorded.
4. Turn off the unit and turn back on. Once light is lit and staying on, touch the dark purple wire 6
times in a row to a ground. After the 6 times turn unit off and turn back on. Codes should be
cleared with the unit working properly. If not continue to step 5.
5. Double check the codes using steps 1 through 3. Once you know what the codes are you can use
this chart to tell where or what the problem may be.
6. Once you have determined what the problem is and make the necessary repairs the unit should
work normally. If the light is still on after the repair you will need to clear the codes using step 4.
Trouble Code Problem Diagnosis
41-42-43-44-45-51
Electric motor
Malfunction
Replace Motor Assembly
11-13-14-15 Torque Sensor Replace Motor Assembly
52-54-55 ECU Malfunction Change Computer
22 No Engine Input Change Computer
21-23-24 No Speed Signal Change Computer
12
Wiring or
Electrical
Verify 12 volts at small red wire. Verify
good ground. Soldier all connections.
Check for bad connections or broken wires.
