3.1.3 Removable Head Option
The removable head option allows the user to easily remove the bundle for cleaning or
inspection, available on all models.
REMOVABLE HEAD
COALESCING MEDIUM / BUNDLE
REFERENCE SUBMITTAL DATA
FOR DISTANCE REQUIRED
TO REMOVE BUNDLE
Figure 3-4 Removable Head Detail
Depending on the size of Aar-O-Vent, the bundle can be quite heavy. It is
recommended that supports be used when removing the head and bundle. Once
all bolts have been removed from the head, the head and bundle are free to drop.
Risk of severe personal injury and/or property damage may occur if the bundle
and head are not supported.
