Section 3
Component Identification and Information
3.1 Component Identification
The following paragraphs contain functional descriptions for each of the major
components of a Thrush Co. Aar-O-Vent. This manual provides information for multiple
Aar-O-Vent models. All the components listed have the same functional purpose in each
model.
(2/4) SIGHT GLASS
ASME NAMEPLATE
REMOVABLE HEAD
BLOW DOWN VALVE
(2) GAUGE TAP
SKIM VALVE
AIR ELIMINATOR
COALESCING MEDIUM
(NOT SHOWN)
OPTIONAL EQUIPMENT
*
*
*
*
LIFT LUGS (2)
(5" & LARGER)
Figure 3-1 Components
