Classic-Craft
Door Panel
Dimensions
Comp 3 2014 (U1 REVISED) 3.61
8/0 Classic-Craft Rustic Doors
4-55/64”
95-3/64”
52-1/64”
22-5/8”
7”
A
B
4-25/32”
C
4-1/2”
95-3/64”
8-35/64”
B
C
D
53-1/8”
22-5/8”
6-1/4”
F
A
E
Size A B C
3/0 26-3/16” 35-3/4” 17-7/8”
3/6 32-3/16” 41-3/4” 20-7/8”
Size A B C D E F
3/0 27-3/8” 35-3/4” 4-3/16” 4-25/32” 11” 4-3/16”
3/6 33-3/8” 41-3/4” 7-3/16” 4-25/32”13-3/4” 4-11/16”
8’ Radiused 2 Panel Plank Round Top
(Trimmable-CCR8225U1)
(Factory Machined-CCR8225RU1)
(Impact-CCR8225HRU1)
8’ 2/3 Arch Lite 2 Panel
(2551A-1W, 3151A-1W)
(Slab-CCR8040NRU1)
(Trimmable-CCR8040U1)
8-35/64”
Daylight Opening:
(2551A-1W)
24-7/16" x 50-5/32"
(1226 sq.in.)
Daylight Opening: 30-3/8" x 50-1/8"
(3151A-1W) (1495 sq.in.)
