Classic-Craft
Door Panel
Dimensions
3.14 2014 (U1 REVISED) Comp 3
6/8 Classic-Craft Canvas Doors
NOTE: 3/0 only.
NOTE: 3/0 only.
C
D
79-3/64”
E
35-3/4”
A B
4-57/64”
18-5/16”
79-3/64”
42-29/32”
8-33/64”
35-3/4”
25-13/16” 4-31/32”
TYP.
4-27/64”
A B C D E
27-17/32” 4-7/64” 3-41/64” 68-9/32” 7-1/8”
27-1/2” 4-1/8” 3-25/32” 68-1/4” 7-1/64”
26-7/32” 4-49/64”
TYP.
2-5/64”
TYP.
17-17/32”
25-1/32”
T
LITE
DESCRIPTION
NON WROUGHT
IRON
WROUGHT
IRON
Craftsman Lite 1 Panel Plank
Flush-Glazed
(Slab - CVNF3026U1)
Full Lite w/ Stile Lines
(2566, 2566-1W)
(Slab - CCV050U1, CCV205NRU1,
CCV220U1, CCV455NRU1,
CCV200U1, CCV060U1)
Daylight Opening:
(Wrought Iron)
24-1/2" x 65-1/4"
(1599 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-17/32" x 65-9/32"
(1602 sq.in.)
Daylight Opening: 17-17/32" x 25-1/32"
(439 sq.in.)
