Composite Outswing Sill
UNDERSIZE LENGTHS
"A"
SILL
LENGTH
"G"
OVERALL
LENGTH
6 = 6" DISPLAY
5.530
6.000
10 = 10" SIDELITE
10.000
10.470
12 = 12" SIDELITE
12.000
12.470
14 = 14" SIDELITE
14.000
14.470
20U = 20 SIDELITE
24.000
24.470
24U = 2/4 DOOR
28.000
28.470
26U = 2/6 DOOR
30.000
30.470
28U = 2/8 DOOR
32.000
32.470
21U = 2/10 DOOR
34.000
34.470
30U = 3/0 DOOR
36.000
36.470
36U = 3/6 DOOR
42.000
42.470
407U = 4/0 DOUBLE 7/8" ASTRAGAL 48.718
49.188
487U = 4/8 DOUBLE 7/8" ASTRAGAL 56.718
57.188
507U = 5/0 DOUBLE 7/8" ASTRAGAL 60.718
61.188
547U = 5/4 DOUBLE 7/8" ASTRAGAL 64.718
65.188
587U = 5/8 DOUBLE 7/8" ASTRAGAL 68.718
69.188
607U = 6/0 DOUBLE 7/8" ASTRAGAL 72.718
73.188
707U = 7/0 DOUBLE 7/8" ASTRAGAL 84.718
85.188
407U* = 4/0 DOUBLE 7/8" ASTRAGAL 48.718
49.188
487U* = 4/8 DOUBLE 7/8" ASTRAGAL 56.718
57.188
507U* = 5/0 DOUBLE 7/8" ASTRAGAL 60.718
61.188
547U* = 5/4 DOUBLE 7/8" ASTRAGAL 64.718
65.188
587U* = 5/8 DOUBLE 7/8" ASTRAGAL 68.718
69.188
607U* = 6/0 DOUBLE 7/8" ASTRAGAL 72.718
73.188
707U* = 7/0 DOUBLE 7/8" ASTRAGAL 84.718
85.188
48U = 4/8 2-PANEL PATIO
57.000
57.470
50U = 5/0 2-PANEL PATIO
61.000
61.470
54U = 5/4 2-PANEL PATIO
65.000
65.470
58U = 5/8 2-PANEL PATIO
69.000
69.470
60U = 6/0 2-PANEL PATIO
73.000
73.470
24U*0 = 2/4 WITH 1-10" SIDELITE
39.000
39.470
24U*2 = 2/4 WITH 1-12" SIDELITE
41.000
41.470
24U*4 = 2/4 WITH 1-14" SIDELITE
43.000
43.470
26U*0 = 2/6 WITH 1-10" SIDELITE
41.000
41.470
26U*2 = 2/6 WITH 1-12" SIDELITE
43.000
43.470
26U*4 = 2/6 WITH 1-14" SIDELITE
45.000
45.470
28U*0 = 2/8 WITH 1-10" SIDELITE
43.000
43.470
28U*2 = 2/8 WITH 1-12" SIDELITE
45.000
45.470
28U*4 = 2/8 WITH 1-14" SIDELITE
47.000
47.470
21U*0 = 2/10 WITH 1-10" SIDELITE
45.000
45.470
21U*2 = 2/10 WITH 1-12" SIDELITE
47.000
47.470
21U*4 = 2/10 WITH 1-14" SIDELITE
49.000
49.470
30U*0 = 3/0 WITH 1-10" SIDELITE
47.000
47.470
30U*2 = 3/0 WITH 1-12" SIDELITE
49.000
49.470
30U*4 = 3/0 WITH 1-14" SIDELITE
51.000
51.470
36U*0 = 3/6 WITH 1-10" SIDELITE
53.000
53.470
36U*2 = 3/6 WITH 1-12" SIDELITE
55.000
55.470
36U*4 = 3/6 WITH 1-14" SIDELITE
57.000
57.470
7/
8"
AS
TR
AG
AL
ST
AN
DA
RD
MU
LLI
ON
STANDARD LENGTHS
"A"
SILL
LENGTH
"G"
OVERALL
LENGTH
48WU = 4/8 2-PANEL PATIO
57.500
57.970
50WU = 5/0 2-PANEL PATIO
61.500
61.970
54WU = 5/4 2-PANEL PATIO
65.500
65.970
58WU = 5/8 2-PANEL PATIO
69.500
69.970
60WU = 6/0 2-PANEL PATIO
73.500
73.970
24WU*0 = 2/4 WITH 1-10" SIDELITE
39.500
39.970
24WU*2 = 2/4 WITH 1-12" SIDELITE
41.500
41.970
24WU*4 = 2/4 WITH 1-14" SIDELITE
43.500
43.970
26WU*0 = 2/6 WITH 1-10" SIDELITE
41.500
41.970
26WU*2 = 2/6 WITH 1-12" SIDELITE
43.500
43.970
26WU*4 = 2/6 WITH 1-14" SIDELITE
45.500
45.970
28WU*0 = 2/8 WITH 1-10" SIDELITE
43.500
43.970
28WU*2 = 2/8 WITH 1-12" SIDELITE
45.500
45.970
28WU*4 = 2/8 WITH 1-14" SIDELITE
47.500
47.970
21WU*0 = 2/10 WITH 1-10" SIDELITE
45.500
45.970
21WU*2 = 2/10 WITH 1-12" SIDELITE
47.500
47.970
21WU*4 = 2/10 WITH 1-14" SIDELITE
49.500
49.970
30WU*0 = 3/0 WITH 1-10" SIDELITE
47.500
47.970
30WU*2 = 3/0 WITH 1-12" SIDELITE
49.500
49.970
30WU*4 = 3/0 WITH 1-14" SIDELITE
51.500
51.970
36WU*0 = 3/6 WITH 1-10" SIDELITE
53.500
53.970
36WU*2 = 3/6 WITH 1-12" SIDELITE
55.500
55.970
36WU*4 = 3/6 WITH 1-14" SIDELITE
57.500
57.970
24U10 = 2/4 WITH 2-10" SIDELITES
50.000
50.470
24U12 = 2/4 WITH 2-12" SIDELITES
54.000
54.470
24U14 = 2/4 WITH 2-14" SIDELITES
58.000
58.470
26U10 = 2/6 WITH 2-10" SIDELITES
52.000
52.470
26U12 = 2/6 WITH 2-12" SIDELITES
56.000
56.470
26U14 = 2/6 WITH 2-14" SIDELITES
60.000
60.470
28U10 = 2/8 WITH 2-10" SIDELITES
54.000
54.470
28U12 = 2/8 WITH 2-12" SIDELITES
58.000
58.470
28U14 = 2/8 WITH 2-14" SIDELITES
62.000
62.470
21U10 = 2/10 WITH 2-10" SIDELITES
56.000
56.470
21U12 = 2/10 WITH 2-12" SIDELITES
60.000
60.470
21U14 = 2/10 WITH 2-14" SIDELITES
64.000
64.470
30U10 = 3/0 WITH 2-10" SIDELITES
58.000
58.470
30U12 = 3/0 WITH 2-12" SIDELITES
62.000
62.470
30U14 = 3/0 WITH 2-14" SIDELITES
66.000
66.470
36U10 = 3/6 WITH 2-10" SIDELITES
64.000
64.470
36U12 = 3/6 WITH 2-12" SIDELITES
68.000
68.470
36U14 = 3/6 WITH 2-14" SIDELITES
72.000
72.470
70U = 7/0 TRIPLE PATIO
86.000
86.470
76U = 7/6 TRIPLE PATIO
92.000
92.470
80U= 8/0 TRIPLE PATIO
98.000
98.470
86U = 8/6 TRIPLE PATIO
104.000 104.470
90U = 9/0 TRIPLE PATIO
110.000 110.470
24WU10 = 2/4 WITH 2-10" SIDELITES
51.000
51.470
24WU12 = 2/4 WITH 2-12" SIDELITES 55.000
55.470
24WU14 = 2/4 WITH 2-14" SIDELITES 59.000
59.470
26WU10 = 2/6 WITH 2-10" SIDELITES 53.000
53.470
26WU12 = 2/6 WITH 2-12" SIDELITES 57.000
57.470
26WU14 = 2/6 WITH 2-14" SIDELITES
61.000
61.470
28WU10 = 2/8 WITH 2-10" SIDELITES 55.000
55.470
28WU12 = 2/8 WITH 2-12" SIDELITES 59.000
59.470
28WU14 = 2/8 WITH 2-14" SIDELITES 63.000
63.470
21WU10 = 2/10 WITH 2-10" SIDELITES 57.000
57.470
21WU12 = 2/10 WITH 2-12" SIDELITES 61.000
61.470
21WU14 = 2/10 WITH 2-14" SIDELITES 65.000
65.470
30WU10 = 3/0 WITH 2-10" SIDELITES 59.000
59.470
30WU12 = 3/0 WITH 2-12" SIDELITES 63.000
63.470
30WU14 = 3/0 WITH 2-14" SIDELITES 67.000
67.470
36WU10 = 3/6 WITH 2-10" SIDELITES 65.000
65.470
36WU12 = 3/6 WITH 2-12" SIDELITES 69.000
69.470
36WU14 = 3/6 WITH 2-14" SIDELITES 73.000
73.470
70WU = 7/0 TRIPLE PATIO
87.000
87.470
76WU = 7/6 TRIPLE PATIO
93.000
93.470
80WU = 8/0 TRIPLE PATIO
99.000
99.470
86WU = 8/6 TRIPLE PATIO
105.000 105.470
90WU = 9/0 TRIPLE PATIO
111.000
111.470
