Classic-craft rustic – Therma-Tru ARCH 2 Architectural Details - U1 Revised User Manual
Page 49
Architectural
Details
Arch 2
2014 (U1 REVISED)
2.49
Classic-Craft Rustic
SECTION B-B
Scale: 3”
= 1’- 0”
SECTION C-C
Jacketed Urethane
Weatherstrip
Brickmould
4-9/16” Jamb
Foam Core
Moisture-Resistant
End Rail
Scale: 3”
= 1’- 0”
4-9/16”
Flush-Glazed
Double-Glazed
Foamed-in-Place
Lite
5-3/4
Sill
” Composite
or Hardwood
Top Rail
