Video Jack
(BNC/RCA)
DC 12V
Power Jack
Power (+)
Power (-)
Video Signal
Video GND
Video Jack Power Jack
(DC 12V)
INSTALLATION
1.Draw out the power/video wires
to the installation area.
2. Connect the power/video jacks
to the camera.
3. Screw up in the camera to the desired
location using the tapping screws.
CAMREA BASE
3
FIXING SCREW
CAMREA
CAMREA COVER
ROTATE 360°
TILT 90°
PAN 360°
Cable Jack Setting
TOP SIDE
DC650F / DC650FB
DIMENSIONS
SPECIFICATIONS
108
83
41
42
How to arrange the cable How to Open the cover
Fig 1. Fig 2.
arrow direction and swing
Insert coin into the slot to
to up or down to open the
dome over.
. 2 . 1
L A P C S T N
1/3" Color CCD
650TV lines
768(H)x494(V) 753(H)x582(V)
2:1 Interlace
Internal
0.00002 Lux(Sens-up)
52 dB or more (AGC Off)
1Vp-p Composite 75Ω
AWC / MANUAL / PUSH
ON / OFF Selectable
OFF / AUTO (x2 ~ x1024)
ON / OFF Selectable
OFF / LOW / MIDDLE / HIGH selectable
ON / OFF (4 Area)
ON / OFF, Color, Position (8 zone)
ON / OFF
Built-In OSD
ON /OFF (Level Adjustable 1 ~ 50)
COLOR / BW / AUTO / EXT
3.6mm Fixed IR Board Lens
DC 12V(±10%)
400mA
-10°C ~ +50°C
30% ~ 90% RH
Weight
Lens
Sharpness
Power Source
Scanning Frequency
Power Consumption
Operating Temperature
Electronic Shutter Speed
Operating Humidity
Dimension (mm)
Scanning System
Synchronization
S/N ratio
Horizontal Resolution
Min.lllumination
MODEL D-650F / D-650FB
Video Output
CCD
TV System
Effective Pixels
Sens-up
D-WDR
OFF / ON (LOW / MIDDLE / HIGH) selectable 3-DNR
AGC
Motion Detection
Day & Night
HLM
Privacy Function
BLC
White Balance
DPC
15.734KHz / 60Hz 15.625KHz / 50Hz
1/50~1/100,000sec 1/60~1/120,000sec
Indoor
Outdoor
Visible Range
(LED non)
-
-
185g
108mm (W) x 83mm (H)
