INSTALLATION
Dimensions
How to Install
Cautions
① Connect Video & Power Line
② Please set the position where you
want to connect the camera.
③ Loosen the locking screws and
adjusting camera angle.
④ Combine each camera parts and lock
& tight the each locking screws.
E D I S T N O R F
80
75
156
92
2.5mm
“L”wrench
Fixing Screw
Mount base
Camera guard
360
180
110
。
。
。
SPECIFICATION
L A P C S T N
1/3" High Sensitivity CCD
650TV lines
768(H)x494(V) 753(H)x582(V)
2:1 Interlace
Internal
0.00002 Lux(Sens-up)
52 dB or more (AGC Off)
1Vp-p Composite 75Ω
AWC / MANUAL / PUSH
ON / OFF Selectable
OFF / AUTO (x2 ~ x1024)
ON / OFF Selectable
OFF / LOW / MIDDLE / HIGH selectable
ON / OFF (4 Area)
ON / OFF, Color, Position (8 zone)
ON / OFF
Built-In OSD
ON / OFF (Level Adjustable 1 ~ 50)
COLOR / BW / AUTO / EXT
3.6mm Fixed Board Lens
DC 12V(±10%)
400mA Max
-10°C ~ +50°C
30% ~ 90% RH
g 0 7 4 ) g (t h gi e W
75mm (W) x 92mm (H) x 156mm(W)
Lens
Sharpness
Power Source
Scanning Frequency
Power Consumption
Operating Temperature
Electronic Shutter Speed
Operating Humidity
Dimensions (mm)
Scanning System
Synchronization
S/N ratio
Horizontal Resolution
Min.lllumination
MODEL BC650F24
Video Output
CCD
TV System
Effective Pixels
Sens-up
D-WDR
OFF / ON (LOW / MIDDLE / HIGH) selectable 3-DNR
AGC
Motion Detection
Day & Night
HLM
Privacy Function
BLC
White Balance
DPC
15.734KHz / 60Hz
1/60~1/120,000sec
15.625KHz / 50Hz
1/50~1/100,000sec
) A E 4 2 - ei p 5 D E L R I ( m 5 2 r o o d nI
20m ( IR LED 5pie -24EA ) Outdoor
Visible Range
(LED non)
Option
Accessory
OSD Controller
