8
EXPOSURE
EXPOSURE
HBLC/D-WDR
AGC
3D DNR
SENS-UP
RETURN
LOW
X16
MID
LENS ELC
OFF
1-3. AGC
D. D-WDR : This function allows to effectively observe the scene with different illumination levels.
A. AGC : The AGC (Auto Gain Control) menu is used to set the AGC level of the camera.
When the AGC is active, the camera automatically increases the sensitivity by
amplifying the Video signal when the strength of the signal falls below the normal value.
Selection of AGC level.(OFF / LOW /MID / HIGH)
D-WDR LEVEL : Selection of D-WDR LEVEL value manually in the range 0~20.
RETURN : Pressing RETURN moves to a higher-level menu.
EXPOSURE
EXPOSURE
HBLC/D-WDR
AGC
3D DNR
SENS-UP
RETURN
LOW
X16
MID
LENS ELC
OFF
1-4. 3D DNR
A. 3D DNR : 3D Digital Noise Reduction shows better picture by reducing noise from the screen,
in low light condition.
Selection of 3D DNR level.(OFF / LOW /MID / HIGH / AUTO)
EXPOSURE
EXPOSURE
HBLC/D-WDR
AGC
3D DNR
SENS-UP
RETURN
LOW
X16
MID
LENS ELC
OFF
1-4. SENS-UP
A. SENS-UP : This allows clear picture even in low light condition.
Selection of SENS-UP level.(OFF / AUTO / X2~X1024)
