Hampton H300 Cast Freestanding Woodstove
PARTS LIST
PARTS LIST
H300 MAIN ASSEMBLY
Part # Description
1) 220-160 Grill Cast - Top
2) 220-371 Stove Top - Charcoal Grey
220-374 Stove Top - Ivory
220-375 Stove Top - Timberline Brown
3) 220-522 Firebox Assembly - Top
4) 220-514 Baffl e Assembly
5) 220-028 Back Shield
6) 220-431 45 Degree Elbow - Charcoal Grey
7) 220-140 Main Cast - Back
8) 220-130 Inner Cast - Back
9) 220-240 Cast Baffl e Retention - Left
10) 220-230 Cast Baffl e Retention - Right
11) 220-381 Left Side Cast - Charcoal Grey
220-384 Left Side Cast - Ivory
220-385 Left Side Cast - Timberline Brown
12) 220-032 Brick Vermiculite - Left Side
13) 936-299 Gasket Tape
14) 220-029 Side Shield Door
15) 220-041 Brick Vermiculite - Right Door
16) 936-236 Graphite Rope
17) 220-351 Right Side Cast - Charcoal Grey
220-354 Right Side Cast - Ivory
220-355 Right Side Cast - Timberline Brown
18) 220-361 Right Side Door - Charcoal Grey
220-364 Right Side Door - Ivory
220-365 Right Side Door - Timberline Brown
19) 948-151 Side Door Hinge
20) 220-053 Door Latch Bar - Right
21) 220-047N Side Door Latch
22) 948-153 Oak Handle
23) 220-120 Firebox Inner Cast - Front
24) 200-160 Andiron Hampton
25) 220-321 Front Vents - Charcoal Grey
220-324 Front Vents - Ivory
220-325 Front Vents - Timberline Brown
Part # Description
26) 220-110 Firebox Cast - Front
27) 220-090 Latch Bar
28) 220-331
Front Skirt - Charcoal Grey
220-334 Front Skirt - Ivory
220-335 Front Skirt - Timberline Brown
29) 220-341 Stove Base - Charcoal Grey
220-344 Stove Base - Ivory
220-345 Stove Base - Timberline Brown
30) 220-401 Side Ashlip - Charcoal Grey
220-404 Side Ashlip - Ivory
220-405 Side Ashlip - Timberline Brown
31) 220-084 Draft Control Lever
32) 220-074 Cam Housing Primary
33) 220-019 Primary Air Cable
34) 220-082 Primary Air - Slide Plate
35) 220-081 Primary Air - Slide Guide
36) 936-238 8mm Soft Fibre Gasket - Black
37) 220-085 Base Sub Cast
38) 220-391 Ashlip - Charcoal Grey
220-394 Ashlip - Ivory
220-395 Ashlip - Timberline Brown
39) 220-421 Standard Leg - Charcoal Grey
220-424 Standard Leg - Ivory
220-425 Standard Leg - Timberline Brown
200-931 Short Leg - Charcoal Grey
200-935 Short Leg - Timberline Brown
40) 220-078
Ash Drawer Holder
41) 220-516 Ash Pan Drawer Assembly
42) 220-917 Optional Blower/Fan (120V)
220-538 Rear Heat Shield Assembly
43) 220-064 Rear Heat Shield - Bottom
44) 220-065 Rear Heat Shield - Top
45) 942-110 Ash Plug
46) 820-249 Ash Plug Tool Handle
47) 220-086 Ash Drawer Holder Cover Plate
48) 948-157
Primary Air Handle
