Buffalo Technology WHR3-G54 - Manual (Page 58)

58
Management - System Information
System information of the AirStation is
obtained here.
• Model name
- Displays model and
fi rmware version
• AirStation Name
- Displays AirStation
host name
• DHCP Server function
- Displays On
or Off
• Wireless
- Displays the wireless LAN
settings such as wireless MAC address
and wireless fi rmware. The wireless
MAC address is required for setting up
WDS with other access points. This is
the best place to determine the wireless
MAC address. If 125 Mbps AfterBurner
mode is enabled, then the [AfterBurner]
color will be read or grey. When it is red,
125 Mbps AfterBurner is running. When it is grey, 125 Mbps AfterBurner is enabled but not running due to
a client being connected at 54 Mbps or another access point is running on the same channel.
• LAN
- Displays the AirStation LAN settings
• WAN - Displays the AirStation WAN settings
• Default Gateway - Displays the default gateway settings
Advanced Settings
System
Information
