Basic Menu
Code Parameter Options Description
ConF Wiring mode 3OP2 3-wire open delta using 2 CTs
4Ln3 4-wire Wye using 3 PTs (default)
3dir2 3-wire direct connection using 2 CTs
4LL3 4-wire Wye using 3 PTs
3OP3 3-wire open delta using 3 CTs
3Ln3 4-wire Wye using 2 PTs
3LL3 4-wire Wye using 2 PTs
3bLn3 3-wire Broken delta using 2 PTs, 3 CTs
3bLL3 3-wire Broken delta using 2 PTs, 3 CTs
Pt Ratio PT ratio 1.0

- 6,500.0 The potential transformer ratio
Pt Factor
Ct CT primary current
1-50,000A
(5*)
The primary rating of the current transformer
PowDmdPer Power demand period
1, 2, 5, 10, 15*, 20,
30, 60, E The length of the period for power demand calculations, in
minutes. E = external synchronization
Num.Per.
Number of power
demand periods 1-15
(1*)
The number of demand periods to be averaged for sliding window
demands
1 = block interval demand calculation
ADmdPer.
Ampere/Volt demand
period 0-1800
(900*) The length of the period for volt/ampere demand calculations, in
seconds. 0 = measuring peak current
Frequency Nominal frequency 25, 50, 60, 400 (Hz) The nominal power utility frequency
MaxDmdLd
- Default setup
Communication Port Menu
COM1 setting
Code Parameter Options Description
Protocol Communications protocol ASCII  , rtu, dnP3
ASCII, Modbus RTU (default) or DNP3.0
protocol
Interface Interface standard 485 RS-485 interface (default)
Address Address ASCII: 0 (default) - 99, Modbus: 1 (default) -247, DNP3.0: 0 (default) -255
Baud Rate Baud rate 110, 300, 600, 1200, 2400, 4800, 9600 (default), up to 115,200 bps
Data/Party Data format 7E, 8E (7/8 bits, even parity), 8n (default) (8 bits, no parity)
Snd.Delay
