31 • Setup Mode Eagle Instruction Manual
5. Press the AIR/▲ or SHIFT/▼ buttons to display the available
target gas labels for the toxic gas channel (H2S, CO, SO2, Cl2,
NH3
, CO2 (5.00%), CO2 (10000 PPM), CO2 (5000 PPM), ***, and
NOT USED ).
6. Press the POWER/ENTER button to enter the new target gas label.
If you entered a label other than ***, continue with step 7. If you
entered ***, go to the next section, “Setting a custom target gas label.”
7. To exit the Gas Combinations menu, press the SHIFT/▼ button
until the prompt is next to Channel 4, then press the SHIFT/▼
button again. The
ESCAPE message displays.
8. Press the POWER/ENTER button. The message SAVING DATA
displays, then the main menu displays.
Setting a Custom Target Gas Label
1. With the prompt next to the target gas label setting (***), press the
POWER/ENTER button. The first asterisk flashes.
2. Press the AIR/▲ and SHIFT/▼ buttons to display the desired
character. Available characters are A through Z, 0 through 9, and a
blank space.
3. Press the POWER/ENTER button to enter the displayed character.
The next character flashes.
4. Repeat steps 2 and 3 to enter the remaining characters. When you
enter the last character, the prompt flashes.
Updating the Fullscale Setting
1. Press the SHIFT/▼ button to place the prompt in the second line,
then press the POWER/ENTER button. The fullscale setting
flashes.
The maximum fullscale setting for a toxic gas channel is 1000 PPM;
the minimum setting is 1.00 PPM. The default setting is 10.0 PPM.
2. Press the AIR/▲ and SHIFT/▼ buttons to display the desired
fullscale setting, then press the POWER/ENTER button to enter
the setting. The prompt flashes.
NOTE: The display increment setting automatically updates its
default setting as you change the fullscale setting.
* * *
1 . P
0
0
>
0 P M
1 . P P M
