Bigstuff3 GEN3 PRO SEFI DAE Option - User Manual
Harness Label
Wire Color /
Connector Type
Label
Definition
Connect To Further Details
ECU Header
Connector Black 30-Way
Connector N/A GEN3 ECU Header
Connector Marked
“DAE” See
Harness_Main_Connec
tor
Analog Trigger Yellow wire Used to
trigger the
DAE data
logging An On/Off switch
(not provided) See Analog_Trigger
Turbo Shaft
Speed Gray, 2-way
Packard connector
with a separate
ground wire (3/8”
ring terminal) Turbo(shaft)
Speed Sensor Two (2) wire VR
style speed sensor
(not a Hall-effect
device). See
Turbo_Shaft_Speed
Turbo Back
Pressure Black 3-way
Packard connector
with a purple seal A Pressure
transducer
which
measure back
pressure 1/8” pipe thread, 0 –
150-psi pressure
transducer Available
separately from
BigStuff3 See
Turbo_Back_Pressure
Input Shaft
Speed Gray, 2-way
Packard connector
with a separate
ground wire (3/8”
ring terminal) Input (shaft)
Speed Sensor Two (2) wire VR
style speed sensor
(not a Hall-effect
device). See Input_Shaft_Speed
Drive Shaft
Speed Gray, 2-way
Packard connector
with a separate
ground wire (3/8”
ring terminal) Drive-shaft
Speed Sensor Two (2) wire VR
style speed sensor
(not a Hall-effect
device). See Drive_Shaft_Speed
Pan Vacuum Orange 3-way
connector with an
green seal Measures
positive and
negative
pressures in
the engine oil
pan +/- 2 Bar MAP
sensor. Available
separately from
BigStuff3 See Pan_Vacuum
Fuel Pressure Black 3-way
Packard connector
with a purple seal Measures fuel
rail pressure 1/8” pipe thread, 0 –
150-psi pressure
transducer. Available
separately from
BigStuff3 See Fuel_Pressure
Oil Pressure Black 3-way
Packard connector
with a purple seal Measures
engine oil
pressure 1/8” pipe thread, 0 –
150-psi pressure
transducer. Available
separately from
BigStuff3 See Oil_Pressure
4
