Technical Specifications
Legion 11,000mAh
Battery
Weight
Human Interface
Fail Safe
Charge Input
Intellectual Properties
Storage Temperature
Charge Output
Enclosure
Operating Temperature
Meters
Display
Power Supply
Physical Dimensions
Lithium Polymer 11,000mAh
0 – 45 Deg Celsius
PLX proprietary intelligent battery monitoring and metering.
USB Female A 5.0V Combined 4A (11,000mAh)
-10 – 45 Deg Celsius
Processor controlled high efficiency DC/DC Boost with low power sleep
Micro USB 5.0V 2.5A
3.87 x 5.50 x 0.52” (9.83 x 13.98 x 1.33cm)
Temperature monitoring, overcharge protection, short circuit and current over-
draw protection
High Contrast OLED 128 x 32 Pixels
9oz
Voltage, Current (in/out), Power, Actual Capacity, Charge Status, Temperature,
Age, Time to Empty, Time to Charge, Health
1 Push Button
ABS Plastic
Patents Pending
