Manual Text Booklet – Orbit Baby Stroller Seat and Stroller Base – ENGLISH – 9
⚠
WARNING
⚠
◦
Listen for audible CLICK which indicates that the stroller seat is locked into the SmartHub.
◦
Always check that the stroller seat is securely locked into the SmartHub by tugging
upwards and turning.
◦
Lock the stroller wheels and check stability of the stroller seat before placing your child in or
removing your child from the stroller seat.
◦
Stroller seat rotation must always be locked in position before moving. Do not rotate the
stroller seat when the stroller is in motion.
◦
Lock the parking brakes and check stability when the stroller is stationary.
Attaching the stroller seat
⃞ Your stroller seat comes folded in the box.
⃞ To unfold, place the stroller seat hub Ⓔ flat on the ground and push back on the top of the stroller
seat until it locks into the upright position. You will hear a CLICK.
⚠
WARNING
⚠
◦
If you do not hear the CLICK sound, the seat is still in the folded position. Do not use in this
position. Push backwards on the top of the seat to lock it in the upright position.
⃞ Dock the seat into a SmartHub Ⓕ and rotate it to one of the locking positions. You will hear a
CLICK when it locks into one of the use positions.
Assembling the stroller seat (required for initial assembly, storage and travel only).
⃞ Locate the snack tray Ⓒ,support bar Ⓓ, and footrest Ⓖ in the box.
⃞ Assemble the sunshade Ⓐ (sold separately) by inserting both sunshade mounts into the upper set
of holes on the stroller seat. You will hear a CLICK.
