8 – ENGLISH – Manual Text Booklet – Orbit Baby Stroller Seat and Stroller Base
Unfolding the stroller base
⃞ Your stroller base comes folded in the box.
⃞ Holding the twist grip Ⓡ in your left hand, push out on the fold lock Ⓣ with your right thumb.
⃞ Rotate the handlebar upward with your right hand.
⃞ Lock the handlebar in place. You will hear a CLICK.
Assembling the stroller base (required for initial assembly, storage and travel only)
⃞ Pull metal tab and insert the rear wheel Ⓦ into the rear leg. Once axle is fully inserted, release metal
tab, and pull out on wheel to check the rear wheel is locked in place. Repeat with other side.
⃞ Insert the front wheels Ⓚ into the front cross brace. You will hear a CLICK when they are locked in
place.
⃞ To assemble the cargo basket Ⓤ, hook the handle onto center of the front basket spar. Insert the
cargo basket handle into the rail on the underside of the SmartHub. You will hear a CLICK when it
locks in place.
⃞To secure the front of the basket, insert one of the plastic handles into the opening on the front part
of the stroller base. Hold it in place while inserting the other plastic handle into the opening on the
other side of the stroller base.
⚠
WARNING
⚠
PINCH HAZARD:
◦
When docking your stroller seat or adjusting your stroller, keep hands and fingers, especially
of children, clear of moving parts and the SmartHub.
◦
Never pull the release levers when the stroller seat is in folded position. This may damage
the stroller seat.
◦
Keep the SmartHub area clean. Keep all metal and plastic parts clear of objects, debris and
liquids to allow proper and safe functionality. Never place the stroller seat in sand or other
surfaces with fine, loose particles.
