Page 7

PI
SA
SW2
SW3
Port 2 (UTP) Modes of Operation
AN
FDX
Configured for Auto Negotiation.
It advertises and negotiates in this order:
1000FDX, 1000HDX
AN
HDX
Configured for Auto Negotiation.
It advertises:
1000HDX
MAN
FDX
Configured for Forced Negotiation.
It advertises:
1000FDX
MAN
HDX
Configured for Forced Negotiation.
It advertises:
1000HDX
Port 2 (UTP) Configuration Matrix
3.2.1.3
SW4 and SW5 - Port 2 Pause Advertisement “OFF PAUSE” “OFF ASYM”
These DIP-switches are only valid when Port 1 is set to “MAN”. The PAUSE modes will be based on the
configuration of DIP-switches SW4 and SW5.
SW4
SW5
Port 2 (UTP) PAUSE Modes
OFF
OFF
No Pause advertised
OFF
ASYM
Asymmetric PAUSE towards link partner
PAUSE
OFF
Symmetric PAUSE
PAUSE
ASYM
Both Symmetric PAUSE and Asymmetric PAUSE
toward local device
Port 2 Pause Modes
