PI

Module - iConverter Gx AN iConverter, Serial Agent

Identifier -

Chassis Number

= 19

Slot Number

= 13

Model Number

= 8500N-0

Serial Number

= xxxxxxxx

Manufacturing Date = xxxxxxxx

Product Revision

= xx

Software Revision

= xx

LED

Switch

ON Condition

OFF Condition

H/W

Actual

1: Power

= On

1: Port 1 Manual

Port 1 AN

Off

Off

2: Not Available

2: Port 2 Manual

Port 2 AN

Off

Off

3: Port 1 Link

= On

3: Port 2 HDX

Port 2 FDX

Off

Off

4: Not Available

4: Pause Disable

Pause Enable

Off

Off

5: Not Available

5: Asym Pause

Sym Pause

Off

Off

6: Not Available

6: Link Propagate

Link Segment

Off

Off

7: Not Available

7: Remote Fault

Normal

Off

Off

8: Port 2 Duplex

= Off

8: Symm Fault Det

Normal

Off

Off

9: Port 2 Link

= Off

Toggle Switch(1-8), (I)dentifier, (S)FP, (R)eset, (H)elp >

The Module configuration screen provides general information concerning the configuration and status of
the module. The screen displays the model and serial numbers, hardware and software revisions, as well as
the condition of the LEDs and DIP-switches. The DIP-switches can be re-configured (options 1 -8) without
removing the module from the chassis. Select the appropriate option to change the DIP-switch setting.
Selecting DIP-switch options 1 - 8, will cause the selection to change states under the ‘Actual’ heading.
