3.4 VERIFYING OPERATION
PI SA
Once the module has been installed and configured, per Sections 3.2 - 3.3, verify the module is operational
by viewing the status of the LED indicators. The table below provides a description for each LED indicator.
The Power LED indicates the module is receiving power from the chassis.
The Fiber Optic “FO” LED indicates the fiber optic connection between the modules has been established.
A blinking LED indicates the presence of data, an auto-negotiation problem or a link mode error indication.
The UTP LEDs indicate the module has established a connection across its UTP port. A blinking LED
indicates the presence of data.
Refer to Section 6.0, Troubleshooting Guide, for help in determining possible fault conditions.
PI SA PI SA
LED Function
"Legend"
Color Off State On / Blinking State On / Blinking State
Power "Pwr" Green No power On: Module has power On: Module has power
1000Mbps
Fiber Optics
"P1" Green No Fiber Link
On: Fiber Link
Fast Blinking: Fiber Data Activity
Slow Blinking: Signal detect but
auto-negotiation has not completed
or SFD error detected
On: Fiber Link
Fast Blinking: Fiber Data Activity
Slow Blinking: Signal detect but
auto-negotiation has not completed
or SFD error detected
Port 2 (UTP)
1000Mbps
"P2"
Green Not linked
On: UTP linked at 1000Mbps
Fast Blinking: UTP Data Activity
Slow Blinking: SFD error detected
On: UTP linked at 1000Mbps
Fast Blinking: UTP Data Activity
Slow Blinking: SFD error detected
Port 2 (UTP)
Full-Duplex
"FDX"
Green
Half-Duplex when
any UTP link is
active
On: Full-Duplex when any UTP link
is active On: Full-Duplex when any UTP link
is active
