8
E
X
HAUS
T
AI
R
F
L O W
INLE
T
IN
ON
OFF
VE NT
Casing Grommet
Black Rubber
5 /
8
″ (15.9mm) CPVC
(Loose parts bag)
Drain Connector Black PVC
3 /
4
″ (19.1mm) PVC X 1 /
2
″
(12.7mm) CPVC
(Loose parts bag)
25--24--68
Single Pressure Switch Details
Dual Pressure Switch
Tee Trap White PVC
(loose parts bag)
2 ″ (50.8mm)
PVC
Coupling
Barbed Coupling, 1 /
2
″ (12.7mm) OD
(loose parts bag)
Rotate
downward
5
° to 10°
NOTE: Built--in channel will
be angled 5
° to 10° also.
SIDE VIEW
Plastic Cap
Yellow or black
Vent Drain
& Clamps
On Some Models
ONLY
Either: The PVC Drain
Tee or a field supplied
2
″ (50.8mm) PVC Tee Relief Tube
Black Rubber
3 /
16
″ 〈4.8mm) ID
Elbow Tubes (2) Black Rubber
1 /
2
″ (12.7mm) ID & Clamps
(loose parts bag)
Drain Tube
Corrugated
5 /
8
″ (15.9mm) ID &
Clamps
Drain Line Vent Tee 3 /
4
″
(18.1mm) PVC or 1 /
2
″
(12.7mm) CPVC (Field sup-
plied)
A07708
Fig. 8 -- All Models Vent Through Right Side (Upflow)
359AA
V
