17
Dimensions and specifications may be changed without prior notice
Electrical Data
Housing
Copper-Zinc alloy
Die Cast
Housing surface
Nickel plated
other surface upon request
Inserts (for contacts)
Thermoplastic Polyamid PA 6 (Nylon 6/6), PBT
Fire protection class V-0
Contacts
Brass Alloy
Contact surface at point of contact
Nickel and gold plated (0,25μm Au)
Minimum mating cycles
> 1000
Seals / O-Rings
Buna-N standard, optional Viton
®
(Viton is a registered trademark of DuPont)
Temperature range
-40° C – 125° C (-40 °F – 257 °F)
Type of contacts
Crimp, dip-solder (PCB)
Protection
IP 67 / IP 69 K per EN 60 529 (connected), NEMA 4x
Cable diameter range
2 – 11 mm (.08 – .43“)
Materials and Technical Data
Mechanical Data
M 16 Control Signal Connectors
Technical Data
Number of positions
Number of contacts
Contact-Ø [mm]
AWG [mm
2
]
Nominal current
1)
[A]
Nominal voltage
2)
[V~]
degree of protection 3
4)
Test voltage (Breakdown voltage)
3)
[V~]
Insulation resistance [MΩ]
Max. contact resistance [mΩ]
Number of positions
Number of contacts
Contact-Ø [mm]
AWG [mm
2
]
Nominal current
1)
[A]
Nominal voltage
2)
[V~]
degree of protection 3
4)
Test voltage (Breakdown voltage)
3)
[V~]
Insulation resistance [MΩ]
Max. contact resistance [mΩ]
1), 2), 3), 4)
See Technical Information page 14
3 (3 x 1 mm)
3 (3 x 2 mm)
4 + 3 + PE / 320 V
4 + 3 + PE / 630 V
3
3
4
4
4
4
1
2
0,8
1,6
0,8
1,25
0,14 – 1
0,5 – 2,5
0,08 – 0,34
0,34 – 1,5
0,08 – 0,34
0,34 – 1,5
8
20
5
16
5
16
400
400
160
320
300
630
2500
2500
1500
2500
1500
2500
> 10
10
> 10
10
> 10
10
> 10
10
3
3
3
3
3
6+PE
10
12 + 3
18
7
10
12
3
18
1,25
1
0,8
1,25
0,8
0,5 – 1,5
0,14 – 0,75
0,08 – 0,34
0,5 – 1,5
0,08 – 0,34
16
8
3
10
3
630
160
24
60
24
2500
1500
1500
2500
1500
> 10
10
> 10
6
> 10
10
> 10
10
3
3
3
3
3
